Wireless table top display stand controller Wireless controller RX-M2811
Wireless table top display stand controller is the core component of ADCS system. It’s the important intercommunication factor of transceiver, wireless table top display stand and software. It can control all of the wireless conference function via the navigation keyboard of the panel, and LCD.
- Technical Specs
Ø Restmoment original full digital conference technique, compliant to IEC 60914 and IEC 60065 international standard.
Ø Adopting 2.4G digital radio frequency communication technology. Multilevel error correction and encrypted coding, has high confidenti ality and low error rate.
Ø Can control all of the vote function via the navigation keyboard of the panel
Ø Adopt high speed RISC embedded hardware structure, more reliable, faster.
Ø 2.8 inch LCD, display Chinese & English.
Ø Dual-machine backup functionality, when one main unit have problem, another main unit ensure the system work on.
Ø Has 4 communication ports for wireless RF transceiver which uses RS 485 protocol.
Ø Bi-directional authentication mechanism
Ø Main unit could start sign-in, vote function, LCD display the result.
Ø Support key sign in,later sign in, display actual sign in situation.
Ø Main unit with new sign-in, new vote, new polling, new respond,new score, setup, result display function.
Ø Support IC card sign-in, ID recognize, IC key and setup language fun ction.
Ø The distance between main unit and Voting transceiver at most reach 1.2 km
Ø Main unit connect computer with RS232 protocol
Ø Adapt of aluminum cover, hazardous materials, passed RoHS.
Ø 2U standard design, could put it in 19 inch rack cabinet.
Ø Cooperate with software, can implement more functions.Keywords:
- Wireless electronical display conference system-Wireless table top display stand controller Wireless controller
AC100~120V, 8A / AC220~240V, 4A
Static state 25W, Maximum 250W
Digitai Wireless Data
256 pcs; It can be expanded
Chinese/English or custom made
Voltage of unit output port
Dual controllers backup
Unit ID number
RJ45 / USB
Unit transmission mode 2.4G wireless Net weight 8KG Color Dark grey
19 inch normal stand
