8.8 inch single side solid wood nameplate RX-6622


Wired electronical display:8.8 inch TFT real color screen on single side.Solid wood outside appearance with high end feeling.

Product number:RX-6622

Download:

  • Description
  • Technical Specs
  • Connection
  • Ø Adopt high speed RISC embedded hardware structure, more reliable and faster.

    Ø Solid wood outside appearance with high end feeling.

    Ø Streamline design, fashion and elegance.

    Ø 8.8 inch TFT real color screen on single side.

    Ø Built-in SD card saving. Users can change the contents in SD card by wired or wireless modes.

    Ø Displayed by photos. User can preset many photos inside.

    Ø “Hand by hand in line” or “Wireless” or “Individual control” connection modes.

    Ø Each unit has arbitrary distribution ID address, convenience for installation and avioding ID address repeating.

    Ø The whole system can be extended to 65535 units.

    Ø Working with management software to achieve more functions.

    Keywords:
    • Wired electronical display conference system-8.8 inch single side solid wood nameplate
  • Mode

    RX-6622

    Type

    Tlectronic nameplate

    Capacity

    ≤65535

    Working power

    12VDC,1A

    Maximum power

    12W

    Control type

    RS-485 or wireless or individule control

    Dimension of back screen

    8.8 inch 1280(H) X 320(V) real color TFT LCD Display

    Color depth

    16.7M

    Edit ID

    RS-485 or Distributed by system controller in wireless mode

    Loading

    RS-485 or Wireless or SD card

    Connection mode

    RS-485 “Hand in hand connection” or Individual connection

    Mount

    RS-485 BIG6 PIN DIN

    Color

    Solid wood color(dark red)

    Net weight

    0.5kg

    Dimension

    261×66×94 mm

    Installation

    Tabletop
