Network digital amplifier RX-KS4300/RX-KSD4300

Network TCP/IP control. It can realize multiple device management. Software control. It can control media matrix, professional processor at the same time

Product number:RX-KS4300/RX-KSD4300

Category：

Sound reinforcement system

Download：

Message Us

Description
Technical Specs
Connection

Ø Network TCP/IP control. It can realize multiple device management.

Ø Remote switch ON/OFF

Ø Adopt color LCD display

Ø Built-in DSP digital processor

Ø Support multiple connection methods: USB, TCP/IP, RS232, RS485

Ø Real-time remote monitoring of the working status

Ø The power amplifier can be identified by software

Ø Support balanced XLR input and unbalanced RCA input

Ø Support stereo, bridge, mono and free matrix modes. One key switch.

Ø The input sensitivity can be adjusted in two steps: 0dBu/6dBu. It can be set by software or color LCD screen.

Ø The power-on state can be set as Power On/Standby

Ø Constant voltage and constant resistance support: 100V, 70V, 8 ohms, 4 ohms

Ø Software control. It can control media matrix, professional processor at the same time
Keywords:
- Network digital amplifier

Model	RX-KS4300	RX-KSD4300
Power	4×300W 8Ω 4×500W 4Ω
Bridge power	2×1000W 8Ω
Input interface	Balanced input 4×XLR; Phoenix terminal input×4
Output interface	Terminal × 4
Input EQ	31-band parametric equalization
Input noise gate	Start control time 1～2895ms, release time 1～2895ms, start control level -120dBu～-60dBu
DSP matrix	4×4 matrix
Output EQ	10-band parametric equalization
Input source	Analog, DANTE, pink noise, white noise, sine wave
DANTE	No	Yes
