Full Digital Conference Controller RX-V4.8
Product number:RX-V4.8
Download：
- Description
- Technical Specs
- Connection
-
- Adopt the original ADCS full digital conference technology. Comply with IEC60914 international standard.
- Five microphone management modes (support speaking microphone 1 ~ 6)
- The controller has the three-in-one function. It can be setup as a system controller, backup controller, or extension controller.
- The controller supports dual backup function.
- The system supports up to eight partitions for input and output.
- 4 HDMI input channels and 2 HDMI output channels, cross-switching.
- Supports HDMI1.3 and HDMI1.4b. And it is compatible with DVI1.0 protocol.
- Support max 4Kx2K@30HZ resolution for input. And it is compatible with 1080P and SD signals;
- Supports seamless switching without black screen signal.
- Built-in noise door
- Microphone can be setup to volume gain adjustment or automatic gain adjustment.
- The microphone has bass cutting function.
- Microphone has 5 EQ equalization adjustment. And each microphone can set a special EQ and volume adjustment.
- The input interface of line 1 can be setup as microphone input or linear input.
- The line input and output have independent volume adjustment function.
- The controller can connect computer, central control and HD video matrix.
- Supports video tracking for up to 4 cameras.Ø
- Supports up to 100 delegate requests in speech sequences. And supports real-time request sequences on PC software
- Can design any microphone as VIP unit. Support 150 chairman units.
- Works with the conference management software to get one-click backup and restoration function.
-
Type
Parameter
RX-V4.8
Working Power
AC100－240V，50/60Hz，4A
Power consumption
Single 6W, Maximum 320W
Display screen
5.0-inch / 480×854 graphic lattice /16.7M color IPS Capacitive touch screen
Single capacity
20pcs conference microphones
System capacity
Multi-functional conference unit 120pcs, and it can be extended to 4095pcs
Transmission distance
Max 150M
Microphone output interface voltage
24VDC
Audio input
RCA x 1 11dBV；XLR x 1 11dBV
Audio output
RCA x 1 10dBV；XLR x 1 16dBV
Output impedance
RCA：650Ω；XLR：460Ω
Frequency response
20~20KHz
SNR
＞90dB
Dynamic range
＞90dB
The total harmonic distortion
< 0.05%
Capacitor microphone port
1 way
Conference unit numbering
Can be customized
The max quantity of chairman units
120pcs
Characteristic function
Supports one backup controller; Supports multiple extended controllers; Max supports 99 controllers.
Serial port control
RS-232 x1
Working modes
Five modes
Quantity of speaking microphone
1～6
Speaking time limit function
Yes
Video control mode
RS-422 / RX-485
Unit connector
6 PIN DIN
Ball capacity
4pcs
Panoramic quantity
Can set 4X4 Panorama points; Can set the switching time and order
Color
Black
Net weight
8KG
Dimension
432×90×350 mm
Installation
Suitable for 19-inch standard rack
