Full digital interpretation system-4 Channel interpretation receiver unit RX-E304/XP


Adopt Restmoment full digital conference technology, compliant to IEC 60914 and IEC 60065 international standard.Modularization embedded design, smart and fashion.System can receive 3+1 interpretation languages.

Product number:RX-E304/XP

Download:

  • Description
  • Technical Specs
  • Connection
  • Ø Adopt Restmoment full digital conference technology, compliant to IEC 60914 and IEC 60065 international standard.
    Ø Modularization embedded design, smart and fashion.
    Ø Can be embedded on the table or under the table.
    Ø Connected by net cable. Transmission distance can reach 100M.
    Ø Frequency response can be 45Hz-20KHz; SNR is over 85dB; Channel separation is over 75Db.
    Ø System self-checking function. Also it has hot-plug/hot-un-plug function.
    Ø Receiver units can be used after be plugged. There is no complex setting up.
    Ø System can receive 3+1 interpretation languages.
    Ø Units are powered by controller; It adopts 24V safe voltage.
    Ø Hand by hand connection in line, or be connected by distribution box or hand by hand connection in ring.
    Ø No editting ID number for each receiver. It is convenient to add or deduct receivers.
    Ø Built-in channel selector which can receive 4 languages. It has individual indicator light.
    Ø 3.5mm earphone output jack. Can adjust volume by dial knob.
    Ø System has channel selector indicator.
    Ø It has power off memory function to keep the channel number after power off.

    Keywords:
    • Full digital interpretation system-4 Channel interpretation receiver unit
  • Parameter\mode

    RX-E304/XP

    Capacity of each controller

    ﹤200pcs

    Capacity of system

    Depends on the quantity of controllers,﹤4096pcs

    Frequency response

    45 ~ 20KHz

    SNR

    85Db

    Dynamic range

    85Db

    Total harmonic distortion

    ﹤0.3%

    Channel separation

    75dB

    Channel number

    4CH

    Working power

    24DC, -5%

    Working current

    20mA +/-5%

    Max consumption

    0.5W

    Earphone output

    16Ω, 250mW/32Ω, 125Mw

    Control type

    RS-485

    Channel indicator

    Individual indicator light

    Connection type

    Hand by hand connection in line, or be connected by distribution box or hand by hand connection in ring.

    Unit mount

    RJ45 × 2

    Dimension of opening hole

    91 x 35mm

    Dimension of panel

    125 x 46 mm

    Color

    Grey, Black, Silver

    Installation

    Embedded
