8 Channel Power Manager RX-PM8000/8S

There are two items: Single control: all 8 channels are normally open contacts; Double control: 8 channels have both normally open and normally closed contacts. It has One NET network control interface to communicate with the programmable controller.

Product number:RX-PM8000/8S

Category：

Audio/video matrix and peripheral equipments

Download：

Message Us

Description
Technical Specs
Connection

Ø There are two items: Single control: all 8 channels are normally open contacts; Double control: 8 channels have both normally open and normally closed contacts.

Ø It has One NET network control interface to communicate with the programmable controller.

Ø Power supply: 24V DC power supply provided by the central control controller.

Ø Control type: controlled by independent network protocol

Ø Maximum load capacity: single-channel current 10A; maximum load capacity 2200W/channel

Ø ID selection: Users can set the network ID identification code through the knob to realize the RS-485 network communication with the programmable controller.

Ø It can control single or multiple switches

Ø Comprehensive indication, support POWER indication, ID network connection indication, and receiving data indication.

Ø Built-in photoelectric isolation module to ensure the safety of the load and the controller.

Ø Dimensions: 434H×158W×43D (mm)

Ø Weight: 2.5kg
Keywords:
- 8 Channel Power Manager

Model	RX-PM8000/8S
Number of replays	8PCS
Load capacity	Single power 10A
ID selection	Network ID Identity Code
Communication method	RS-485 bus control
Control type	24VDC network power supply
Dimension	434H×158W×43D (mm)
Weight	2.5kg
