Audio/video matrix and peripheral equipments-4-Channel Dimming Relay RX-MD8000
It has 4-channel adjustable light interface, single-channel power ≥ 2000W It has One NET network control interface to communicate with the programmable controller.
Product number:RX-MD8000
Download：
- Description
- Technical Specs
- Connection
-
Ø It has 4-channel adjustable light interface, single-channel power ≥ 2000W
Ø It has One NET network control interface to communicate with the programmable controller.
Ø Power supply: 24V DC power supply provided by the central controller
Ø Control method: control through RS-232 protocol
Ø Maximum load capacity: single current 10A, maximum current 20A
Ø Comprehensive indication. It supports POWER indication and Receiving data indication
Ø Built-in photoelectric isolation module to ensure the safety of the load and the controller
Ø Dimensions: 380H×200W×70D (mm)
Ø Weight: 3.5kg
Keywords:- Audio/video matrix and peripheral equipments-4-Channel Dimming Relay
-
Model
RX-MD8000
Light Modulators
4 Channel
Load capacity
Single channel current 10A
ID Selection
Network ID code
Communication method
RS-232 bus control
Control type
24V DC network power supply
Dimensions
380 X 200 X 70(mm)
Weight
3.5 kg
-
