Series 4K HD Camera RX-HV4K812

HD camera with 12X optical zoom. The network interface supports 10M/100M/1000M adaptive Ethernet port. And it supports POE power supply. Supports audio and video output

Product number:RX-HV4K812


  • Description
  • Technical Specs
  • Connection
  • Ø 1/2.8 inch SONY CMOS sensor, 8.5 million pixels 16:9

    Ø Video signal: 4Kp60/50/30/25, 1080p60/50/30/25, 1080I60/50, 720p60/50/30/25

    Ø Lens: 12x optical zoom, f=4.0~50.4mm

    Ø Horizontal viewing angle: 6.55° (narrow angle)-69.4° (wide angle); Vertical viewing angle: 3.66° (narrow angle)-42.8° (wide angle)

    Ø Support SM-2D and SM-3D digital noise reduction, SNR>55dB, low illumination 0.5Lux (F1.8, AGC ON); aperture F1.8–F2.8

    Ø Video adjustment: brightness, chroma, saturation, contrast, sharpness, black and white mode, gamma curve and other functions

    Ø Support auto/manual white balance, auto/manual focus mode, auto/manual exposure mode

    Ø Video supports HDMI, USB3.0 (compatible with USB2.0), LAN (POE). Three ways simultaneous output 4K signal

    Ø Has one channel audio input port, one channel RS232 control port, and one channel 422 control port (compatible with RS485)

    Ø LAN port supports H.265/H.264 video compression; USB supports MJPG, H.264, YUY2, NV12

    Ø The audio port supports AAC, MP3, G.711A audio compression, and the audio input port is dual channel 3.5mm linear input.

    Ø Network protocol support: RTSP, RTMP, ONVIF, GB/T28181; support network VISCA control protocol;Support remote upgrade, remote restart, remote reset

    Ø Control protocol supports VISCA, PELCO-P/D protocol, supports automatic identification protocol

    Ø Audio output: HDMI, LAN (POE) network ports. It supports audio signal output

    Ø The USB port is compatible with Windows 7, Windows8, Windows10, Mac osx, Linux and other operating systems; USB supports UVC (video communication protocol), UAC (audio communication protocol)

    Ø The network interface supports 10M/100M/1000M adaptive Ethernet port, supports POE power supply, supports audio and video output

    Ø The gimbal supports 255 preset positions, horizontal speed: 100°/sec, tilt speed: 45°
