Auto video tracking camera-Speed done came RX-TV320
DSP digital technology design. Compacted structure, stable operation, low noise, stable picture.
Product number:RX-TV320
Download：
- Description
- Technical Specs
- Connection
-
Ø DSP digital technology design. Compacted structure, stable operation, low noise, stable picture.
Ø Main part adopt high strengt Aluminum alloy. Impact proof, screening and thermolysis .
Ø Color camera, universal variable dome and mulitfunction decoder together.
Ø RS485 bus control. Signal transmission remotely with no interference.
Ø Color camera shooting. Horizontal resolution reach to 480 lines. The image is clearer and more natural.
Ø 18 times photics zooming, 4 times electron zooming.
Ø Built-in 64 adjustable prearranged point and 6 automatically cruise track.
Ø Horizontal 360° infinite continued rotation. Vertical 90° rotation. The speed reach to 120°/s.
Ø 180° automatic overturn. Monitor omnidirectional and no blind spot. The accurateness of location reach to ±0.2°.
Ø Automatic aperture and gains、automatic focus, automatic white balance, ultra low illuminance .
Ø Two installation methods: Ceiling type, wall-mounted.
Keywords:- Auto video tracking camera-Speed done came
-
Model
RX-TV320 series
Image sensor
1/4’’color CCD
Effective pixels
752H*582V
Synchronization system
Internal synchronization
Video output
Composite signal
White balance
Automatic/Manual
power supply
AC15V 1.0A
Power consumption
10VA
Weight
2KG
Installation way
Ceiling type, wall-mounted
Relative humidity
10-75% Condensation-free case
Operate temperature
Normal range
Scan system
480 TV line
Resolution is the level
480
SNR
Above 48 db
Electronic shutter
second
Minimum illumination
0.01-1Lux
Zoom range
18 times photics zooming, 4 times electron zooming
Aperture
Automatic/Manual
Zoom
Automatic/Manual
Horizontal rotation
0-300
Tilting
0-120
Preset position
64
Inspection function
Max 6 Tracks
