• Tabletop unit-Table top conference unit RX-C-D2700XP.jpg

Table top conference unit RX-2700XP

Adopt RESTMOMENT conference technology, compliant to IEC60194.Elegance desktop design, accord with ergonomics.

Product number:RX-C2700XP RX-D2700XP


  • Description
  • Technical Specs
  • Connection
  • Ø  Adopt RESTMOMENT conference technology, compliant to IEC60194.

    Ø  Elegance desktop design, accord with ergonomics.

    Ø  Digital audio transfer technique, point to point connection mode. Remote transmission won’t influence on sound quality. Distance between two units could reach to 100m

    Ø  Power supplied by main controller. Input voltage is 24V.

    Ø  Gooseneck pole and high directional electret MIC with red indicator light.

    Ø  Units have double colors & high light LED indicator light.

    Ø  Units are connected by 2M 8pin cable.

    Ø  Hand in hand connecting for units

    Ø  Support “PnP”

    Ø  Built-in high fidelity speaker. If users open the MIC or insert the earphone, it mutes automatically.

    Ø  Each unit has free distributed ID address, convenient for installation.

    Ø  Double stereo earphone output, could adjust volume.

    Ø  5 MIC working modes

    ●   Limited mode

    ●   FIFO mode

    ●   Apply mode

    ●   Voice activating mode

    ●   Free discussion mode

    Ø  Co-operating with camera, it has video tracking function.

    Ø GSM Mobile phone interference free Design Circuit.

    Ø  Camera always tracks the last opened MIC, and system can display conference in real time.

    Ø  Chairman unit has priority, could switch off all the speaking units.

    Ø  System supports 80pcs chairman units simultaneously. And specify one as executive chairman unit.

    Ø  Except having all the functions of delegate unit, the chairman unit also has below functions:

    ●  Speaking priority

    ●  Can switch off speaking delegate unit

    ●  Can reject or approve speaking apply of delegate units

    ●  The position of chairman unit is free

    ●  There are many chairman units in a system

    • Tabletop unit-Table top conference unit
  • Model

    RX-C2700XP series

    RX-D2700XP series


    Table top chairman unit

    Table top delegate unit

    System capacity

    Depends on controller≤4096

    Frequency respond


    MIC type


    Sensitivity of MIC




    Dynamic Range


    Total harmonic distortion

    < 0.05%

    Working power


    Working current

    40mA ±5

    Maximum consumption


    Control type


    Earphone output

    16Ω250mW / 32Ω125mW

    ID edit

    Distributed by main controller

    Connection mode

    Hand in hand


    Big 8 pin DIN

    Video tracking function



    Dark blue


    Table top
