Full digital Economical conference host RX-M3001/V

Ø Restmoment original full digital conference technique, compliant to IEC60914.

Ø Can control the conference via the navigation keyboard of the panel.

Ø Adopt high speed RISC embedded hardware structure, more reliable, faster.

Ø Full digital audio technique, close to CD sound quality, Distance between two units could reach at 150m.

Ø 2.8inch LCD, display Chinese & English.

Ø system checking auto function,  can adjust ID No.

Ø Built in input、output digital volume adjustment.

Ø Built in 8*8 video matrix switch.

Ø Built in 8*4 Panorama video switch.

Ø video tracing with function: camera parameter、Operation options、video matrix and MIC video setup.

Ø System support 120 chairman units, could specify one as executive chairman.

Ø  Support“PnP” .

Ø 2 pcs RS-232 serial port, connect to PC and central control.

Ø RS-422 & RX-485 video control mode. Could switch o RS-232.

Ø Built in balance and non-balance audio input、output connector.

Ø MIC management mode:
   ● Quantity limited mode

   ● FIFO mode
   ● request speech mode

   ● Voice activating mode

   ● free speech mode

Ø 4 line unit output. Every line with 20 units. At most 80 units.

Ø System capacity can be extended by connecting with the extension unit. The max capacity is 65335 units.

Ø System support hand-in-hand connection, Y type connection, Junction box and round type hand-in hand connection.

Ø When single MIC turn off, trace former unit automatically.

Ø Protocols share, compatible with all the pop camera.

Ø Adapt of aluminum cover, hazardous materials, passed RoHS.

Ø 2U standard design, could put it in 19 inch rack cabinet.

Ø Built in Universal power supply and Voltage regulation system.

Ø In combination with the corresponding software modules, more conference function.
