Full digital Economical conference host RX-M3000/V
Full digital main unit is the core component of ADCS system. It’s the important intercommunication factor of conference unit and software. 2.8inch LCD, display Chinese & English.
- Technical Specs
Ø Restmoment original full digital conference technique, compliant to IEC60914 and IEC60065.
Ø Can control the conference via the navigation keyboard of the panel.
Ø Adopt high speed RISC embedded hardware structure, more reliable, faster.
Ø Full digital audio technique, close to CD sound quality, Distance between two units could reach at 150m.
Ø 2.8inch LCD, display Chinese & English.
Ø system checking auto function, can adjust ID No.
Ø Built in input、output digital volume adjustment.
Ø Built in 8*8 video matrix switch.
Ø Built in 8*4 Panorama video switch.
Ø video tracing with function: camera parameter、Operation options、video matrix and MIC video setup.
Ø System support 120 chairman units, could specify one as executive chairman.
Ø Support“PnP” .
Ø 2 pcs RS-232 serial port, connect to PC and central control.
Ø RS-422 & RX-485 video control mode. Could switch o RS-232.
Ø Built in balance and non-balance audio input、output connector.
Ø MIC management mode:
● Quantity limited mode
● FIFO mode
● request speech mode
● Voice activating mode
● free speech mode
Ø 4 line unit output. Every line with 20 units. At most 80 units.
Ø System capacity can be extended by connecting with the extension unit. The max capacity is 65335 units.
Ø System support hand-in-hand connection, Y type connection, Junction box and round type hand-in hand connection.
Ø When single MIC turn off, trace former unit automatically.
Ø Protocols share, compatible with all the pop camera.
Ø Adapt of aluminum cover, hazardous materials, passed RoHS.
Ø 2U standard design, could put it in 19 inch rack cabinet.
Ø Built in Universal power supply and Voltage regulation system.
Ø In combination with the corresponding software modules, more conference function.Keywords:
- Full digital economical controller-Full digital Economical conference host
AC100~ 120V, 8A / AC220 ~240V, 4A
Depends on the quantity of connecting unit: Single unit 25W, Maximum 400w
2.8 inch screen
Chinese/English or custom made
Capacity of each way
150 multi-function units, expandable
Voltage of unit output port
RCA X 2 2V p-p 6.3mm x 1 -50Db XLR x 1 -50dB
RCA X 2 2V p-p
20 ~ 20KHz
Total harmonic distortion
Unit ID number
Quantity of possible chairman units
Serial port control
2 serial ports which can connect PC or programmable central control system
Quantity of turnning on units
Speaking limit function
Video control type
6 pin DIN
Balling unit capacity
Quantity of panorama
8X4 channel can setup switching time & order
Video output level
RCA X 41.08V p-p
Video output impedance
432L x 90H x 350W mm
Suitable for 19 inch standard stand
