Wireless conference controller RX-M2904
Advanced automatic frequency technology. If the frequency of transmitter and receiver are mess, you can press conference unit to search the frequency of transmitter and adjust the frequency same as transmitter’s
- Technical Specs
Ø Adopt UHF super high frequency range; Less interference than traditional VHF and more reliable.
Ø DPLL synthesis of digital phase locked loop multi-channel frequency synthesizer. In 60MHz frequency bandwidth, 300KHz channel apart, it provide 200 channels. Many sets machine can be used simultaneously.
Ø The whole system hardware is controlled by microcomputer CPU, which can be used for frequency selection, display, frequency data processing and automatic channel tracking.
Ø Special receiving sensitivity adjustable function which is used to improve anti-interference capacity or increase receiving distance.
Ø Premium display screen. Can check working status of system controller and units clearly.
Ø The range can be 60M in ideal environment.
Ø Free discussion working mode.
Ø Using 20pcs wireless conference units in same space and same frequency range; If the frequency is not setup properly, it will causes intermodulation interference.
Ø Aluminium alloy case. The material has ROHS certification.
Ø Adopts 1U international standard design which can be installed in 19inch case.Keywords:
- UHF wireless conference system-Wireless conference controller
Wide band FM
80Hz ~ 18KHz (±3dB)
Two frequency conversion heterodyne
First medium frequency: 110MHz; Second medium frequency: 10.7MHz
12 dBμV (80DbS/N)
Max output level
432L x 45H x 236W mm
Suitable for 19 inch standard stand
