  • Full digital system controller RX-V4.3.jpg

Full digital system controller RX-V4.3


Audio and communication adopt full digital conference technology, compliant to IEC60065 international standard. Wired and wireless conference in one controller; One controller can connect wired and wireless units. The controller has a five-in-one function, which can be set as a system controller, a backup controller, an extension controller, a combined controller and a distribution controller.

Product number:RX-V4.3

Download:

  • Description
  • Technical Specs
  • Connection
  • Ø Audio and communication adopt full digital conference technology, compliant to IEC60065 international standard

    Ø Wired and wireless conference in one controller; One controller can connect wired and wireless units

    Ø 5 MIC management modes (Support speaking wired microphone 1pc~6pcs; Support speaking wireless microphone 1pc ~3pcs)

    Ø The controller has a five-in-one function, which can be set as a system controller, a backup controller, an extension controller, a combined controller and a distribution controller.

    Ø Support double machines back-up function to keep the system’s safty and stability.

    Ø The system supports max 8 conference rooms splitting/combined function (optional function)

    Ø Controller audio signal supports 48kHz and 32kHz audio sampling frequency output selection.

    Ø The microphone has a 5-band EQ balance adjustment. And each microphone can be set with a specific EQ and volume adjustment

    Ø The microphone has bass cut function. Built-in noise gate

    Ø It can adjust the automatic/manual gain of each microphone.

    Ø Line 1 input interface can be setup as microphone input or linear input.

    Ø Each channel input and output has independent volume adjustment function.

    Ø The controller has a HD matrix control serial port. And it has a HD video matrix that directly controls the same code to realize video switching.

    Ø The controller has conference audio matrix technology and built-in nx8 audio matrix processor. It can divide all microphones into 8 zones. And each zone has independent audio output. It effectively avoid the microphone whistling problem.

    Ø Support hybrid remote video conference function. It can output the digital audio signal of the conference to the remote video conference terminal through the built-in USB interface of the controller. It realizes the seamless connection of digital audio signal.

    Ø The controller supports 8-channel microphone digital signal output to the computer. And working with the software, it has automatic voice analysis function

    Ø Controller supports multi-channel DANTE protocol

    Ø The controller is connected to the computer through TCP/IP protocol, which can realize remote control maintenance and system upgrade.

    Ø The controller has 1 channel ALARM fire alarm linkage trigger interface, which provides fire alarm information and reminds the attendee to evacuate urgently.

    Ø Support max 100 delegates to apply for speaking sequence; It can display real-time application sequence on PC software.

    Ø System supports 150 chairman units. It could specify any unit as VIP unit.

    Ø Conference monitoring function, dynamic monitoring of the conference process.

    Ø Conference recording and external audio input recording. The cumulative recording time can reach 1500 hours

    Ø Sign-in, voting, response and scoring functions can be initiated directly on the conference controller. And the countdown can be set, and the results can be displayed on the screens.

    Ø You can choose to vote by name or anonymous. And all data can be exported and printed in graphic form.

    Ø Support simultaneous interpretation function.

    Ø Working with the conference management software, it has one-key backup and system recovery functions: the conference management software has the one-key backup import and export function, which can back up all the data of the system controller (including video tracking data, etc.) and save them to the computer; The file is quickly exported to the system controller, then the two controllers has same configuration data.



    Keywords:
    • Full digital system controller
  • Parameter

    RX-V4.3 Series

    Working power

    AC100240V50/60Hz4A

    Working consumption

    Depends on QTY of units: Single 6W, max 320W

    Display

    2.8 inch screen

    Menu

    Chinese/English or custom made

    Capacity of each way

    Conference units:20pcs

    System capacity

    120 units; Can be expanded to 4095 units

    Transmission distance

    Max 100M

    Voltage of unit output port

    24V

    Audio input

    RCA x 2  11dBVXLR x 1  11dBV

    Audio output

    RCA x 2  10dBVXLR x 1  16dBV

    Output impedance

    RCA650ΩXLR460Ω

    Frequency response

    20~20KHz

    SNR

    102dB

    Dynamic range

    106dB

    Total harmonic distortion

    < 0.05%

    External microphone port

    1port

    Unit ID number

    User defined

    Quantity of possible chairman units

    150pcs

    Special function

    Support 1 backup controller; In meeting room combine mode, it supports 8 combined controllers; It supports max 99 controllers

    Serial port control

    RS-232 x 2

    Network port control

    RJ45 x 4

    Working modes

    5 modes

    Quantity of speaking microphones

    1~6

    Speaking limit function

    Yes

    Video control type

    RS-422 / RX-485

    Unit connector

    6PINDIN

    Balling unit capacity

    8PCS

    Quantity of panorama

    Can setup 8X4 Panorama points; Can setup switching time & order

    Recording function Built-in 16G flash memory; External U disk supports a maximum capacity of 64G, and the cumulative recording time is about 1500 hours
    Voting function Yes
    DANTE Yes
    Partition management Yes
     Interpretation Yes

    Color

    Dark grey

    Net weight

    8KG

    Dimension

    432×90×350 mm

    Installation

    Suitable for 19 inch standard stand
