Full digital infrared language distribution system-Full digital infrared radiator RX-H1032XP/35

Infrared radiator can receive signals from infrared controller, and transmits signals to infrared receivers by max 32 channel. It is compatible with the infrared simultaneous interpretation system which is compliant to IEC61603-7. It also can connect to one or many high frequency signal output interfaces on controller. Each output interface on controller can connect max 30pcs radiators by “hand in hand”.

Product number:RX-H1032XP/35

Category：

Full digital infrared language distribution system

Download：

Message Us

Description
Technical Specs
Connection

Ø Adopt Restmoment full digital infrared conference technology, compliant to IEC61603-7 and IEC60914、IEC60065 international standard

Ø Compatible with the infrared simultaneous interpretation system which is compliant to IEC61603-7

Ø Various installation modes: A-frame floor stand, universal wall stand or other installation modes.

Ø Manual full power and half power switch which is convenience to apply in large/medium/small conference halls

Ø Cable transmission delay compensation function, range of delay compensation adjustment is from “00”to“99”

Ø Universal power supply, suitable for worldwide. LED displays signal and working situation real time.

Ø 35W transmitting power, transmitting distance can reach 100M, radiate angle: Horizontal ±40°、Vertical ±22°

Ø HF input/output socket (2xBNC), is used to connect infrared controller/ and series connect next infrared radiator.

Ø Dimension(L X W X H): 500x 319x 178mm

Ø Color: Sliver, Golden, Black

Ø Weight: 7.5kgs
Keywords:
- Full digital infrared language distribution system-Full digital infrared radiator

Model	RX-H1032XP/35
Modulation mode	DQPSK compliant to IEC61603-7
Carrier frequency	2-8MHz
Audio processing	IR-DSP
Infrared radiate power	35W
Working Voltage	AC110/220V
Working temperature	0-40℃
Radiate distance	100M
Half angle radiate angle	Horizontal ±40°、Vertical ±22°
Maximum current consumption	3000mA
Minimum current consumption	150mA
Input impedance	75 Ohm
Carrier wavelength	850nm
Cooling	Convective cooling
LED display	Power/Signal
Dimension	500x319x178mm
Weight	7.5kg（excludes power supply cable）
Color	Silver, Golden, Black
